■ 2 ch 3U and powerful amplifier to drive high power subwoofers.
■ Linear power supply makes it immune to noise and electromagnetic interference.
■ Controlled rail voltage increases efficiency of these amplifiers.
■ Heavy duty Rugged 3U rack mount chassis for durability in touring applications.
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 1800W |
4 Ω Stereo Power |
2 x 3000W |
2 Ω Stereo Power |
2 x 45000W |
4 Ω Bridged mono Power |
4000W |
Weight |
40kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz / +/-0.6dB0.10% |
THD+N(Rated power, 4 Q /KHz)% |
<0.05% |
Signal Noise Ration (db} |
>6000:1 |
Input Impedance |
>20 k Ω />10KΩ |
Output connecters |
Speakon Connectors or 2 pair of binding post output |
Power Reqirment |
240V,50/60Hz |
Dimension (H x W x D) |
140 x 480 x 580 mm |
■ 2 ch 3U and powerful amplifier to drive high power subwoofers.
■ Linear power supply makes it immune to noise and electromagnetic interference.
■ Controlled rail voltage increases efficiency of these amplifiers.
■ Heavy duty Rugged 3U rack mount chassis for durability in touring applications.
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 2000W |
4 Ω Stereo Power |
2 x 3600W |
2 Ω Stereo Power |
2 x 5000W |
4 Ω Bridged mono Power |
5000W |
Weight |
45kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz / +/-0.6dB0.10% |
THD+N(Rated power, 4 Q /KHz)% |
<0.05% |
Signal Noise Ration (db} |
>6000:1 |
Input Impedance |
>20 k Ω />10KΩ |
Output connecters |
Speakon Connectors or 2 pair of binding post output |
Power Reqirment |
240V,50/60Hz |
Dimension (H x W x D) |
140 x 480 x 580 mm |
| Channels | 2 |
|---|---|
| Amplifier Class | TD |
| Power Supply | |
| Power @4Ohm | |
| Size | 3U |
