Renowned for its high power and reliable performance, the amplifier utilizes a 3-stage Class-H amplification design with a toroidal power supply. This combination delivers exceptional power handling, efficiency, and pristine audio output with minimal distortion.
We meticulously craft the amplifier with premium materials, ensuring top-notch quality, stability, and efficiency under any operating conditions.
Additionally, the heavy-duty, rugged 3U rack mount chassis provides exceptional durability for demanding touring applications.
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 800W |
4 Ω Stereo Power |
2 x 1500W |
2 Ω Stereo Power |
2 x 1800W |
4 Ω Bridged mono Power |
3000W |
Weight |
32kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 40, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage turn-on/off transient, Current inrush, Sub Ultrasonic input. |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 8Ω ) |
800:l |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 8Ω ) |
.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon connectors or 2 pair of output insulated gold plated binding posts |
LED Indicators |
Clip/Limit, Signal, Temp/DC, Active |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490mm |
Renowned for its high power and reliable performance, the amplifier utilizes a 3-stage Class-H amplification design with a toroidal power supply. This combination delivers exceptional power handling, efficiency, and pristine audio output with minimal distortion.
We meticulously craft the amplifier with premium materials, ensuring top-notch quality, stability, and efficiency under any operating conditions.
Additionally, the heavy-duty, rugged 3U rack mount chassis provides exceptional durability for demanding touring applications.
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 1100W |
4 Ω Stereo Power |
2 x 1800W |
2 Ω Stereo Power |
2 x 2100W |
4 Ω Bridged mono Power |
5000W |
Weight |
38kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 40, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage turn-on/off transient, Current inrush, Sub Ultrasonic input. |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 8Ω ) |
800:l |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 8Ω ) |
.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon connectors or 2 pair of output insulated gold plated binding posts |
LED Indicators |
Clip/Limit, Signal, Temp/DC, Active |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490mm |
Renowned for its high power and reliable performance, the amplifier utilizes a 3-stage Class-H amplification design with a toroidal power supply. This combination delivers exceptional power handling, efficiency, and pristine audio output with minimal distortion.
We meticulously craft the amplifier with premium materials, ensuring top-notch quality, stability, and efficiency under any operating conditions.
Additionally, the heavy-duty, rugged 3U rack mount chassis provides exceptional durability for demanding touring applications.
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 1450W |
4 Ω Stereo Power |
2 x 2350W |
2 Ω Stereo Power |
2 x 2500W |
4 Ω Bridged mono Power |
6000W |
Weight |
42kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 40, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage turn-on/off transient, Current inrush, Sub Ultrasonic input. |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 8Ω ) |
800:l |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 8Ω ) |
.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon connectors or 2 pair of output insulated gold plated binding posts |
LED Indicators |
Clip/Limit, Signal, Temp/DC, Active |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490mm |
| Channels | 2 |
|---|---|
| Amplifier Class | H |
| Power Supply | |
| Power @4Ohm | |
| Size | 3U |
