This high-powered Amplifiers delivers pristine sonic performance, ideal for driving line array speaker systems.
The meticulously crafted design utilizes premium materials to ensure exceptional stability and efficiency, even under demanding conditions
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 250W |
4 Ω Stereo Power |
2 x 400W |
4 Ω Bridged mono Power |
2 x 800W |
Weight |
29kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 4Ω, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 8Ω ) |
800:1 |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 8Ω ) |
0.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon Connectors |
LED Indicators |
Clip/Limit |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490 mm |
This high-powered Amplifiers delivers pristine sonic performance, ideal for driving line array speaker systems.
The meticulously crafted design utilizes premium materials to ensure exceptional stability and efficiency, even under demanding conditions
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 400W |
4 Ω Stereo Power |
2 x 600W |
4 Ω Bridged mono Power |
2 x 2100W |
Weight |
32kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 4Ω, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 8Ω ) |
800:1 |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 8Ω ) |
0.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon Connectors |
LED Indicators |
Clip/Limit |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490 mm |
This high-powered Amplifiers delivers pristine sonic performance, ideal for driving line array speaker systems.
The meticulously crafted design utilizes premium materials to ensure exceptional stability and efficiency, even under demanding conditions
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 600W |
4 Ω Stereo Power |
2 x 900W |
4 Ω Bridged mono Power |
2 x 1800W |
Weight |
38kg |
This high-powered Amplifiers delivers pristine sonic performance, ideal for driving line array speaker systems.
The meticulously crafted design utilizes premium materials to ensure exceptional stability and efficiency, even under demanding conditions
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 800W |
4 Ω Stereo Power |
2 x 1200W |
4 Ω Bridged mono Power |
2 x 2400W |
Weight |
42kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 4Ω, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 80) |
800:1 |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 80) |
0.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon Connectors |
LED Indicators |
Clip/Limit |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490 mm |
This high-powered Amplifiers delivers pristine sonic performance, ideal for driving line array speaker systems.
The meticulously crafted design utilizes premium materials to ensure exceptional stability and efficiency, even under demanding conditions
| Output | |
|---|---|
8 Ω Stereo Power |
2 x 1000W |
4 Ω Stereo Power |
2 x 1350W |
4 Ω Bridged mono Power |
2 x 2700W |
Weight |
48kg |
| Specification | |
|---|---|
Frequency Response |
20Hz-20kHz,(rated power at 4Ω, 1% THD+N) |
Tour Class Protection |
ACL, IGM, Auto Ramp, short circuit, DC voltage |
THD+N (1kHz) |
<0.03% |
Damping Factor (20-400Hz at 80) |
800:1 |
Signal Noise Ration (db} |
> -70dB |
Input Sensitivity (Rated power at 80) |
0.775V standard (switchable) |
Input Impedance |
20 k Ω />10KΩ |
Input Connectors |
FemaleXLR |
Output connecters |
Speakon Connectors |
LED Indicators |
Clip/Limit |
Power Supply |
240V, 50/60Hz |
Dimension (H x W x D) |
133 x 483 x 490 mm |
| Channels | 4 |
|---|---|
| Amplifier Class | H |
| Power Supply | |
| Power @4Ohm | |
| Size | 2U, 3U |
